Toyota Camry 2016 all keys lost done by Autel IM508 & APB112

This post show you guide on how to use Autel IM508 and Autel AP112 to do all keys lost programming for Toyota Camry 2016.

Procedures:

Connect Autel IM508 to Toyota Camry OBD port,and connect Autel APB 112 to IM508

Enter “IMMO” menu–>Toyota–>Manual Selection–>Other

Then select “Camry”–>Smart key–>Keyless System(CAN)

Now select “Back UP Immobilizer Data”

This function is use to back up the EEPROM data of the smart box of the vehicle.The data can be used to generate the simulator key for emergency start of the vehicle to perform the key matching function.

Click “OK” to continue

Reading immobilizer data (make sure im508 connect to network)

After then save the EEPROM backup data file

Now press “OK” button to back,and select “Generate Simulator Key”

Select the EEPROM data.

Choose the backup file you saved just now

Retrieving critical data…

Key Type:SLK3

It will prompt you to connect APB112 key simulator,press “OK” to continue

Burning firmware please wait…

Now Autel IM508 programmer show you simulator key is generated successfully

Back to menu to select “Add Smart Key”

Press “Yes” to use simulator key

Note:Each step must be completed within the specified time

The positions for learning include:5

Click “OK”

Put the simulator key APB112 close to the START button

Then you will sound a beep,remove simulator key

Put the new smart key to learned close to the start button

After get two warming sound “Beep Beep”,remove new smart key from START button

Registering,please wait…

Learning succeed.

Now you can test the new smart key on vehicle.

Done
