BMW INPA 5.0.6 download – working ok with K+Dcan cable

BMW INPA 5.0.6 download here, which is tested without issues to work with K+DCAN usb cable with inpa bmw e46 and inpa bmw e90. Enjoy!



INPA v5.0.6 download:

https://mega.nz/#F!JJgynb7L!fthUR3q5JMC7hFf4nuvzPQ

Files incl:

EDIABAS v.7.30, Tool32 v.4.03, INPA v.5.06, WinKFP v.5.31 & NCS Expert v.4.01

(BIG THANKS to the contributor Kenny)



Computer requirements:

OS: Microsoft Windows XP, 7 (32/64bit), 8, 8.1 (32/64bit), 10 (32/64bit)

CD/DVD ROM Drive

1 Available USB Port (We recommend using the same USB port each time)

Minimum 1.2GHz Processor

Minimum 2GB of RAM

Intermediate experience with navigating Windows and installing software/drivers

Note:

You’re advised to use INPA software on Windows XP, tested by professional engineers at uobdii.com. bmw inpa windows 7 and bmw inpa windows 10 need luck



How to install inpa/ediabas:

Install BMW Standard tools 212

Copy INPA_Fxx_v.2 folder to C:\EC-Apps\INPA_Fxx_v.2

Copy EDIABAS to C:\EDIABAS overriding existing EDIABAS Folder.

Run INPALOAD.exe from INPA_Fxx_v.2 BIN folder (C:\EC-Apps\INPA_Fxx_v.2\BIN\INPALOAD.exe).



bmw inpa cable:

K+DCAN USB cable is verified to work no issues with INPA BMW.

bmw-inpa-k-dcan-with-switch

It’s the newest K+DCAN cable, released in the 2016 year with two new futures:

Feature 1: 2016 new k+dcan cable adds a switch on the adapter.

kdcan-inpa-cable-switch

the switch on this cable to LEFT is for 7 pin, to RIGHT for 8 pin
8 pin for K-LINE communication (old DCAN cables cannot do it) for BMW from 1998 to 2008
Feature 2- This usb cable improves a lot in the PCB design. The new pcb comes with FT232RQ chip

kdcan-inpa-cable-switch-pcb-1 kdcan-inpa-cable-switch-pcb-2

the printed circuited board of better quality than the old one
INPA bmw and K+DCAN cable test results:

inpa bmw e46:

Purpose: reset BMW E46 airbag light

Tools for use:

The E46 is before 2000 without the OBD2 port and the DLC port is a round 20 pin connector while INPA cable has only 16 pin connector, so I need a 20 pin to 16 pin connector

inpa-k-dcan-bmw-e46-airbag-reset-dlc-port-1

The DLC port location on BMW E46:

inpa-k-dcan-bmw-e46-airbag-reset-dlc-port-2

Test procedure:

Run INPA software on WIN XP. Turn on the ignition and click the “F2” button. And choose “Body” section then “Airbag”.

inpa-k-dcan-bmw-e46-airbag-reset-3

Go to the Error Memory: click the “F4” button.

inpa-k-dcan-bmw-e46-airbag-reset-4

Go to clear error memory: click the “F2” button.

inpa-k-dcan-bmw-e46-airbag-reset-5

Error was cleared!

reset BMW E46 airbag light successfully!

inpa-k-dcan-bmw-e46-airbag-reset-6



inpa bmw e90:

Purpose: Code BMW E90 (2008) Injector

Tools to use: k+dcan cable

Test process:

connect the INPA cable with my E90 N54 via OBD port

run INPA software. And pressed F9 on the keyboard to select vehicle model E90

bmw-inpa-software-1

select Engine option -> MSD80 concerning option

bmw-inpa-software-2

press F9 system diagnostic

bmw-inpa-software-3

press [shift+F4] EOL injector option

bmw-inpa-software-4

The interface of MSD80 injector coding program, Check the injector parameters

bmw-inpa-software-5

copy and paste the injector code and pressed OK to continue

Notice that the injector code are stamped onto the injector in white, there will be 2 rows of 3 numbers, for example, here: 582 227

bmw-inpa-software-6 bmw-inpa-software-7

Finally check the injector value and press [clear] to reset it.
